Description
Network | |
Standard | 4G LTE Cat.4 |
WiFi | 2.4GHz, Support AP Mode/STD Mode/WiFi Direct |
Bluetooth | BLE 4.0 |
Band | Eurasian Version LTE-FDD: B1/B3/B5/B7/B8/B19/B20 LTE-TDD: B38/B39/B40/B41 (100M) WCDMA: B1/B2/B5/B8 GSM: B2/B3/B5/B8 |
Camera | |
Front Camera (Main) | 1920×1080/25FPS/F2.2/Full color/85° (HFoV) |
Peripheral Camera | 1280×720/15FPS/F2.0/Full color in daytime & monochrome in dim light/100° (HFoV) |
Video Format | .ts |
Configuration | |
GNSS | GPS/BDS |
Sensor | 3-axis |
Microphone | Support |
Speaker | Support |
Interface | Micro USB*1, SOS*1, TTL*1, Relay*1 |
Memory Support | TF card (Up to 256GB) |
SIM Card Type | Nano |
LED Indication | Red (Power), Blue (Cellular), Green (GNSS) |
Others | |
Power Supply | Power cable: B+/ACC/GND |
Operating Voltage | DC 9–30V |
Operating Temperature | –20°C to +65°C |
Storage Temperature | –30°C to +85°C |
Device Weight | 233g |
Device Dimension | 109*69*52mm |
Certifications | CE/FCC/RoHS |
